LEDWALL2420IP

Elevate your lighting ambiance with LEDWALL2420IP. Illuminating with 24pcs * 10W 4-in-1 RGBW LEDs, it adapts brilliantly with 20° or 40° lens options. Tailor the atmosphere effortlessly with the magnetic frost filter featuring degrees from 15 to 60.

With a remarkable LED lifetime of 50,000 hours, this fixture ensures enduring radiance. Operating at 100 – 240V 50/60Hz, with a max power of 200W, it guarantees performance.

Control options are comprehensive, offering RDM, DMX 512, and Wireless DMX. Dynamic color temperature ranges from 2000K to 10000K, accompanied by a CRI of 85, light output of 20031 lm, and lux of 34308 lux @ 2m.

Crafted with reliability in mind, its rugged black aluminum body is equipped with active cooling and IP65 waterproofing. Ensured safety features include automatic overtemperature protection and bottom mount for safety wire.

OLED display / 4 buttons ensure intuitive settings. Mounted with 2 x 2 quarter-turn locking points for one or two Omega brackets, its dimensions are 460 x 168 x 314.5 mm with a net weight of 12 kg.

Discover the radiant versatility of LEDWALL2420IP, where light transforms spaces with precision.

SKU: LEDWALL2420IP Categories: , , ,

Description

Elevate your lighting ambiance with LEDWALL2420IP. Illuminating with 24pcs * 10W 4-in-1 RGBW LEDs, it adapts brilliantly with 20° or 40° lens options. Tailor the atmosphere effortlessly with the magnetic frost filter featuring degrees from 15 to 60. With a remarkable LED lifetime of 50,000 hours, this fixture ensures enduring radiance. Operating at 100 – 240V 50/60Hz, with a max power of 200W, it guarantees performance.

Control options are comprehensive, offering RDM, DMX 512, and Wireless DMX. Dynamic color temperature ranges from 2000K to 10000K, accompanied by a CRI of 85, light output of 20031 lm, and lux of 34308 lux @ 2m. Crafted with reliability in mind, its rugged black aluminum body is equipped with active cooling and IP65 waterproofing. Ensured safety features include automatic overtemperature protection and bottom mount for safety wire.

OLED display / 4 buttons ensure intuitive settings. Mounted with 2 x 2 quarter-turn locking points for one or two Omega brackets, its dimensions are 460 x 168 x 314.5 mm with a net weight of 12 kg. Discover the radiant versatility of LEDWALL2420IP, where light transforms spaces with precision.

Specifications

  • Led: 24pcs * 10W 4 in 1 RGBW LEDs
  • Lens: 20°, 40°
  • Magnetic frost filter: 15,25,45,60,60*10 degree
  • LED lifetime: 50,000 hours
  • Voltage: 100 – 240V 50/60Hz
  • Max power: 200W
  • Cabled DMX: 5 pin XLR input/output
  • Control: RDM, DMX 512 & Wireless DMX
  • Color temperature: 2000K – 10000K
  • CRI: 85
  • Light output: 20031 lm
  • Lux: 34308 lux @ 2m
  • DMX channels: 2, 3, 5, 8 & 11 CH
  • Dimming: Electronic
  • Strobe: Ultra-high-speed strobe effects
  • Tilt: 0 – 220°
  • Power Supply Unit: Auto-ranging electronic switch-mode
  • Color options: Black sand coat painting
  • Cooling: Active, Forced Air, Temperature-regulated
  • Temperature Range: -40°C to 45°C
  • Thermal Protection: Automatic overtemperature protection
  • Mounting point: 2 x 2 quarter-turn locking points for one or two Omega brackets
  • Safety features: Bottom mount for safety wire
  • Display and Setting: OLED display / 4 buttons
  • Waterproof: IP65
  • Lens material: PE and tempered glass front
  • Material: Aluminium
  • Dimensions: 460 x 168 x 314.5 mm
  • Weight: 12 kg


Downloads

PDF User Manual
