The WDMX T500DUO MK2 is two transceivers with W-DMX unit in one 19″ housing. Built-in support for DMX and RDM. Powered by Wireless Solution G5, the wireless system transmits or receives safe and reliable DMX data with-out any delay and interference. Ideal for large scale tour, mobile applications and rental market.
Specifications
- Frequency: 2.4 GHz,license free worldwide
- Power: connector: Powercon In and Out
- Control Protocol: W-DMX, RDM
- Operation Modes: Transmitter or Receiver
- Wireless Card: Original Wireless Solution G5
- Modulation Method: AFHSS
- Number Of DMX Ch.: 1024
- Universes Per Device: 2
- Universe In Coexistence: 16 Max.
- Compatibility: W-DMX G3 &G4S
- DMX Latency: <5 ms
- Antenna Type: 5dBi
- Signal Connector: 3pin or 5pin XLR In/Out
- Working Range: 500m (line-of-sight)
- IP Rating: IP20 for indoor use only
- Mounting: Rack or Truss mounting
- Dimensions: 482 x 147 x 44 mm
- Weight: 3 kg
- Certification: CE
