Description
Versatile Wireless DMX Control Hub with 512 Channels, 32 Universes, W-DMX Compatibility, Long Range, and Extended Battery Life.
Specifications
- Input protocols: DMX 512 and RDM ANSI E1.20 (2)
- DMX latency: < 5 ms
- Max.Universes in coexistence: 32
- Input/Output opto isolation
- Error correction (Invisi-Wire)
- W-DMX G3 & G4S compatibility:2.4 GHz,& 5.8 GHz
- Standard range: Up to 400 meters (line of sight)
- Normal Power Mode 2.4 GHz: 100mW
- Maximum Power Mode 2.4 GHz: Up to 450mW
- DMX Connectors:3/5 pin input and output
- AC Input: Eoropean plug with Powercon 3-pole,2.5mm 100 – 250VAC & 50/60 Hz (0.35A @ 115VAC – 0.2A @ 240VAC)
- Supplied Accessories: 2dBi, black, omi-directional antenna
- Weight: 0.8 KG
- Dimensions: L160 x W 110 x H 65 mm
- Installation:
- Metal panel for mounting on the wall
- Omega with fast lock
- M10 holes for C clamp
- Self-tast belt for fix any column
- Temperature Range:-20 °C-45°C
- IP Rating: IP20
