ARC.Z1420IP with the successes of the 1st Generation, we upgrade it with more efficiency led resource, brightness is 30% higher than the G1,the optical angle range of ARC.Z1420IP is 8°-40°. With a brand-new electronic zoom system, it shows high efficient and smooth zoom. Excellent color mixing creates high quality light, without any extra spill light. With its design of IP66, ARC.Z1420IP is the ideal lighting for small/large- scaled show/event.
Specifications
- Light Source: 14x20W (RGBW).
- Beam Angle: 8°-40°.
- Input Voltage: 100-240VAC, 50/60Hz.
- Power: 235W.
- Drive Current: 700mA/1000mA.
- Dimming: 0-100% 16Bit.
- Control Protocol: DMX512, RDM.
- Display: On board Control, 0-20Hz Strobe, Custom Mode.
- DMX Modes: TOUR/12CHS, ARC1/3CHS, AR1.D/4CHS, ARC.2/4CHS, AR2.D/SCHS, AR2.S/6CHS, HSV/3CHS, TR16/17CHS, AR2.Z/7CHS.
- Cooling: Direct Convection.
- Dimensions: 330x283x236mm (SS342XCEM) 375x283x236mm (SS342XCE) 325x283x236mm (SS342XCET).
- Weight: 8.6kg.
- Material: Die-cast aluminum.
- Color: Black.
- Operating Temperature: 20°C-45°C.
- IP Rating: SS342XCE-Dry Location, IP20; IP POWER Socket, IP DMX XLR, SS342XCEM, IP65; SS342XCET-Dry/Damp/Wet Location/lP66 (with LED dispaly cover installed).
- Power Connection: Power in/out.
- DMX Connection: DMX in/out.
- CE, MET.
