The PANEL2200TW is a high-performance Studio LED Panel engineered to deliver premium, customizable illumination for demanding media and broadcast environments. Equipped with 288 LEDs (144 Cool White and 144 Warm White), this 200W fixture offers an adjustable color temperature range from 2800K to 6500K with highly accurate color rendering.
The unit is built for versatility, boasting an IP20 protection rating and multiple operational modes including manual control via an onboard 1.77-inch LCD screen, 8-bit/16-bit DMX control channels, and various pre-programmed cinematic light effects (such as Candle, Fireworks, Paparazzi, and TV simulations). For maximum flexibility on set, it can be powered conventionally through an AC power line or remotely using a 26V V-mount battery.
Specifications
- Light Source: 144pcs CW LED + 144pcs WW LED
- Color Temperature Range: 2800K-6500K (plus or minus 100K)
- Beam Angle: 110 degrees
- Power Consumption: 200W
- Battery: Power Input : DC 26V V-port battery
- Control Protocols: DMX512, RDM
- DMX Channels: P1 (CCT 8Bit 7CH), P2 (CCT 16Bit 10CH), P3 (FX 8Bit 13CH)
- Dimming Curves: Linear, Exponent, S Curve, Log, TV Curve
- Input Power Supply: AC 100-240V, 50/60Hz
- Color: Rendering Index (CRI) : Greater than or equal to 97
- Television Lighting Consistency Index (tlci): Greater than or equal to 97
- Onboard Display: 1.77 inch LCD display screen
- Signal Connections: 5-pin XLR socket input and output
- Firmware Update Method: Via USB port
- Built: in Lighting Effects : Candle, Fire, Fireworks, Paparazzi, Strobe, TV, Explosion, Welding, Lightning, Cloud
- Fan Settings: Off, Low, Auto, High, Full
- Protection Rating: IP20
- Dimensions: 449mm x 382mm x 192mm
- Net Weight: 6.8KG
