The MINIFRESH50TWV2 is a professional, highly compact LED fresnel fixture designed for versatile lighting applications such as news interviews, micro-film shooting, small events, wedding photography, and exhibition lighting. Driven by a 50W warm white and 50W cold white tunable LED engine, it offers adjustable color temperatures ranging from 2,700K to 6,500K.
Engineered for exceptional color rendering, it achieves a CRI of 95, R9≥90, TLCI of 98, and CQS of 96, ensuring natural and vibrant color reproduction. The fixture features a manual zoom ranging from 25° to 80° and delivers a smooth, soft, and flat field of illumination. Operation is silent thanks to low-noise fan cooling, and control is flexible via DMX, RDM, rotary
Specifications
- Light Source: 50W WW + 50W CW tunable LED
- Color Temperature: 2700K~6500K tunable
- CRI/Ra: CRI 95, R9≥90, TLCI 98, CQS 96
- Zoom Range: 25°-80° manual zoom
- Control Protocol: DMX, RDM, Rotary, Key
- DMX Channels: 1/2/3/5 CH
- Rated Lifespan: 50,000 hours
- DMX Compliance: USITT DMX512-A
- RDM Compliance: ANSI/ESTA E1.20
- AC Power: 100-240 V nominal, 50/60 Hz
- DMX And RDM Data In/out: 5-pin XLR (3-pin optional)
- Cooling: Fan cooling (low noise)
- Maximum Ambient Temperature (ta Max.): 45°C
- Minimum Ambient Temperature (ta Min.): -5°C
- Housing: Aluminum
- Color: Black
- Protection Rating: IP20 (Indoor use only)
- Mounting: Adjustable bracket
- Orientation: Any
- Dimensions: 230 x 156 x 279 mm
- Net Weight: 2.2 kg (barn door incl.)
- Gross Weight: 2.8 kg
- Included Items: Power input cable, safety cable, user manual, color frame, barndoor
- Power Connection: Powercon in
