FRES350FC

The FRES350FC is a 350W RGBALC powered LED fresnel with zoom function. The RDM-DMX compliant, 20 – 55 degree motorized zoom along with it’s superior color mixing make this fixture a good replacement for the traditional fresnels.

SKU: FRES350FC Categories: , ,

Description

The FRES350FC is a 350W RGBALC powered LED fresnel with zoom function. The RDM-DMX compliant, 20 – 55 degree motorized zoom along with it’s superior color mixing make this fixture a good replacement for the traditional fresnels.

Specifications

Physical

  • Size: 460 x 320 x 440mm
  • Net Weight: 11 kg(barn door incl.)
  • Gross Weight: 13 kg

Control and programming

  • Control protocol: DMX, RDM
  • DMX channels: 2/8/13
  • DMX compliance: USITT DMX512-A
  • RDM compliance: ANSI/ESTA E1.20

Optics

  • Light source: 350W COB LED
  • Color temperature: 3000K ~ 8000K
  • Zoom range: 20°-55° motorized zoom
  • LED lifetime: 50,000 hours

Construction

  • Housing: Aluminum
  • Color: Black
  • Protection rating: IP20

Installation

  • Mounting: Adjustable bracket
  • Location: Indoor use only
  • Orientation: Any

Connections

  • AC power in, thru: IP rate power cable in
  • DMX and RDM data in/out: 3-pin locking XLR

Electrical

  • AC power: 100-240 V nominal, 50/60 Hz
  • Power consumption figures are typical, not maximum. Allow for +/- 10% variation.

Thermal

  • Cooling: Heat sink( no noise)
  • Maximum ambient temperature (Ta max.): 45° C
  • Minimum ambient temperature (Ta min.): -5° C

Approvals: CE


Downloads

PDF User Manual
PDF Drawing
ZIP Libraries files

Accesories
