HYBRID350CMY

The HYBRID350CMY is a 350W white LED hybrid moving head that features a 8°-35° linear zoom beam angle, and a variety of color options including CMY and a color wheel with 7 colors plus white. It also has 7 gobos, a 5-facet circular prism that can rotate in both directions, and a frost filter for wash effects. The focus is motorized and it has an electronic strobe with a range of 1-25 fps. The dimmer is linear and goes from 0-100%, while the pan and tilt have a range of 540° and 270° respectively. The pan and tilt motor is a 3-phase high speed motor, and the display is a full color LCD. The moving head can be controlled through DMX, Auto, Sound, and Master/slave modes, and it has 20 DMX channels.

SKU: HYBRID350CMY Categories: , ,

Description

The HYBRID350CMY is a 350W white LED hybrid moving head that features a 8°-35° linear zoom beam angle, and a variety of color options including CMY and a color wheel with 7 colors plus white. It also has 7 gobos, a 5-facet circular prism that can rotate in both directions, and a frost filter for wash effects. The focus is motorized and it has an electronic strobe with a range of 1-25 fps. The dimmer is linear and goes from 0-100%, while the pan and tilt have a range of 540° and 270° respectively. The pan and tilt motor is a 3-phase high speed motor, and the display is a full color LCD. The moving head can be controlled through DMX, Auto, Sound, and Master/slave modes, and it has 20 DMX channels.



Specifications

  • Source: 350W white LED,7800K
  • Beam angle: 8°-35°linear zoom
  • Colors: CMY+Color wheel(7 colors+white)
    Gobos: 7 gobos + open, rotating, exchangeable and shaking
  • Prism: 5-facet circular Prism, bi-direction rotating
  • Frost: yes
  • Focus: motorized
  • Strobe: 1-25 fps electronic
  • Dimmer: 0-100% linear
  • Pan/Tilt: 540°/270°
  • Pan/Tilt motor: 3-phase high speed motor
  • Display: full color LCD
  • Working: DMX, Auto, Sound, Master/slave
  • DMX channels: 20 ch.
  • Power connector: PowerCon In & Out
  • DMX connector: 3pin or 5pin XLR In & Out
  • Power in: AC 100-240V 50-60Hz
  • Dimension: 400 x 330 x 560 mm
  • Weight: 16 kg

Downloads

HYBRID350CMY

User manual
