HALOBEAM300

The HALO BEAM 300 is a LED hybrid moving head that offers a powerful 300W white LED and 1610W RGBW 4in1 lights Source that provides an output of 52,000LUX@5M. It has a beam angle of 3°, 11 colors+white, 14 fixed gobos+open and 16-facet Prism that rotates in both directions. It has a motorized focus and 1-25 fps electronic strobe. The dimmer function is linear and has 0-100% range. It has pan and tilt movements of 540°/270° with 3-phase high speed motor. The display is a full-color LCD and it has DMX, Auto, Sound, Master/slave working modes. It has 15 DMX channels and the power connector is PowerCon In & Out and DMX connector is 3pin or 5pin XLR In & Out.

SKU: HALOBEAM300 Categories: , , , ,

Description

The HALO BEAM 300 is a LED hybrid moving head that offers a powerful 300W white LED and 1610W RGBW 4in1 lights Source that provides an output of 52,000LUX@5M. It has a beam angle of 3°, 11 colors+white, 14 fixed gobos+open and 16-facet Prism that rotates in both directions. It has a motorized focus and 1-25 fps electronic strobe. The dimmer function is linear and has 0-100% range. It has pan and tilt movements of 540°/270° with 3-phase high speed motor. The display is a full-color LCD and it has DMX, Auto, Sound, Master/slave working modes. It has 15 DMX channels and the power connector is PowerCon In & Out and DMX connector is 3pin or 5pin XLR In & Out.

Specifications

  • Source: 300W white LED+16*10W RGBW 4in1
  • Beam angle: 3°
  • Output: 52,000LUX@5M
  • Colors: 11 colors + white
  • Gobos: 14 fixed gobos + open
  • Prism: 16-facet Prism, bi-direction rotating
  • Focus: motorized
  • Strobe: 1-25 fps electronic
  • Dimmer: 0-100% linear
  • Pan/Tilt: 540°/270°
  • Pan/Tilt motor: 3-phase high speed motor
  • Display: full color LCD
  • Working: DMX, Auto, Sound, Master/slave
  • DMX channels: 15 ch.
  • Power connector: PowerCon In & Out
  • DMX connector: 3pin or 5pin XLR In & Out
  • Power in: AC 100-240V 50-60Hz
  • Dimension: 270 x 270 x 470 mm
  • Weight: 12.5 kg


Downloads

PDF User Manual
PDF Drawing
