The LASERARRAY12RGB is a high-power linear laser bar featuring 12 calibrated RGB laser apertures. Designed for sharp aerial beam effects, this fixture offers synchronized tilt movement across its entire array, producing vibrant color sequences and high-energy geometric patterns ideal for clubs, stages, and touring productions.
The LASERARRAY12RGB delivers a massive visual impact with 12 high-intensity 2W RGB laser sources aligned in a robust linear array. Unlike standard moving heads, this fixture focuses on creating sweeping “curtains” of light and complex mid-air tunnels through its precision-motorized Tilt axis. It features 16 built-in motor macros and 64 light macros for rapid programming, while its 74-channel DMX mode allows for granular control over the color and intensity of each individual laser head. Built for professional reliability, it includes an intelligent air cooling system and a clear OLED display for seamless operation.
Specifications
- Light Source: 12pcs x 2W RGB Laser (Analog modulation)
- Beam Angle: Parallel Linear Beams
- Input Voltage: 100 – 240 VAC, 50/60 Hz
- Power Consumption: 220W
- Control Protocol: options: DMX512, RDM, Master-Slave, Auto, Sound
- DMX Channels: 14 / 74 CH
- Strobe: Rate: Electronic high-speed strobe
- Display: OLED control panel
- Movement: Motorized Tilt (Y-axis) with fine tuning
- Built: in Macros: 16 Motor macros & 64 Light macros
- Electronic Dimming: 0 – 100%
- AC Power In/thru: PowerCon In & Out
- DMX Data In/thru: 3-Pin XLR In & Out
- Cooling: Intelligent air cooling system
- Housing: Aluminum alloy & Plastic
- Color: Black
- Working Temperature: 0°C – 35°C
- Weight: 23 kg
- Dimensions: 107 x 61 x 52 cm (Package)
- Accessories (incl.): Power cable, User manual
