The SPIDERSPLIT2X4 is a 1U rack mountable DMX/RDM signal amplifier and splitter.
It complies with RDM E1.20-2006 and USITT DMX-512 (1990) protocol, making it a perfect tool for lighting professionals.
The main purpose of this DMX/RDM splitter is to maintain the correct data on long or multiple DMX devices (up to a maximum of 32 devices) and simplify wiring. Ideal for large DMX networks.
Specifications
- Power: Input: Power input: AC 110V or 230V
- Product Type: DMX signal booster & splitter RDM E1.20 compliant
- Configuration: 1 input to 8 outputs or 2 inputs to 8 outputs
- DMX Connector: 3pin or 5pin DMX In
- DMX Thru Connector: 3pin or 5pin DMX Thru
- DMX Out Connector: 3pin or 5pin DMX Out
- Isolation: 100% isolation for all inputs and outputs
- Indicator: Signal & power LED indicator for output
- Signal Handling: Boost/repeat RDM/DMX signals
- Signal Cleaning: Regenerate/clean RDM/DMX signals
- Signal Distribution: Split RDM/DMX signals and build star topologies
- Connectivity: Connect a large number of fixtures to a single universe
- Signal Integrity: Prevent reflection on signal lines
- Mounting Option: Rack or Truss mounting
- Dimensions: 482 x 180 x 45 mm (1U rack mount)
- Weight: 2.5 kg
