Description
ARC.Z340IP stands for the new generation LEDPAR, mix the cutting-edge technology and Classic concept; With one big lens, truly homogenized clean lights, no moreheadache of color dots; The specific precise and smoothzoom system create an incredible range from 4.5-36*: It willnot only a tight beam effect tool, but also perfect for largearea wash. The ARC.Z1420IP is ideal for professional TV, Studio, Theatre, opera, medium to large show /event applications.
Optical system
- Light source: 3x40W (RGBW), (RGBA optional).
- Angle: 4.5°-36°.
Electrical Specs
- Voltage: 100-240VAC, 50/60Hz.
- Power: 130W.
- Drive Current: 2.5A.
- Power Connection: Power in/out.
- DMX xlr: DMX in/out.
Control System
- Dimmer: 0-100% 16Bit.
- Cooling: Direct Convection.
- Control: DMX512, RDM.
- Display: On board Control, Custom Mode, 0-25Hz Strobe.
- Con Personality: HSIC/9CHS, SSP/9CHS, TOUR/12CHS, TR16/17CHS.
Appearance
- Size: 388x274x210mm.
- Weight: 7.3kg.
- Casing: Die-cast aluminum.
- Color: Black.
Work Environment
- Ambient Temp: -20°C-45°C.
- IP Rated: IP65.
Certification
- CE, MET.
