SATURN700RGB

💧 IP65 Rated

Embark on a cosmic journey with the SATURN700RGB, a luminary masterpiece that transcends the ordinary. Illuminated by a constellation of 392pcs 1.5W CW and 784 0.8W RGB lights, this radiant marvel delivers a breathtaking ≥72600LM (Peak value) output, casting an enchanting glow that captivates any audience. Experience the brilliance with an illuminance of 1600Lux@5m over a wide 117º beam angle, while the adjustable color temperature from 2700K to 8000K creates a celestial spectrum of hues. The SATURN700RGB is not just a luminary; it’s an art form. The 28-segment strobe white and 14-segment strobe color RGB Pixel-mappable zones offer dynamic displays, transforming any space into a canvas of visual wonder.

Crafted from an Aluminum-magnesium alloy with a sleek hot paint finish, the SATURN700RGB is not only a powerhouse but a design statement. Its robust IP65 rating ensures resilience against the elements, making it perfect for both indoor and outdoor events. Navigate the cosmos of creativity with Tilt movement reaching 185º and a unique pulse mode in the strobe, adding rhythmic dynamism to your light show. Illuminate with precision using 4 dimming curves and a dimmer that ranges from 0 to 100%, all controlled seamlessly through DMX512/RDM/Art-Net, offering 8/11/13/24/30/70/97 channels for ultimate flexibility.

The SATURN700RGB is not just a luminary; it’s an experience. Discover the universe of possibilities with a TFT Display guiding your control, while a low-noise fan ensures cool serenity during your performance. Weighing in at 12.2kg and accompanied by power cable and x2 integrated clamps, this cosmic wonder is ready to take your events to new dimensions.

SKU: SATURN700RGB Categories: ,

Description

Embark on a cosmic journey with the SATURN700RGB, a luminary masterpiece that transcends the ordinary. Illuminated by a constellation of 392pcs 1.5W CW and 784 0.8W RGB lights, this radiant marvel delivers a breathtaking ≥72600LM (Peak value) output, casting an enchanting glow that captivates any audience. Experience the brilliance with an illuminance of 1600Lux@5m over a wide 117º beam angle, while the adjustable color temperature from 2700K to 8000K creates a celestial spectrum of hues. The SATURN700RGB is not just a luminary; it’s an art form. The 28-segment strobe white and 14-segment strobe color RGB Pixel-mappable zones offer dynamic displays, transforming any space into a canvas of visual wonder.

Crafted from an Aluminum-magnesium alloy with a sleek hot paint finish, the SATURN700RGB is not only a powerhouse but a design statement. Its robust IP65 rating ensures resilience against the elements, making it perfect for both indoor and outdoor events. Navigate the cosmos of creativity with Tilt movement reaching 185º and a unique pulse mode in the strobe, adding rhythmic dynamism to your light show. Illuminate with precision using 4 dimming curves and a dimmer that ranges from 0 to 100%, all controlled seamlessly through DMX512/RDM/Art-Net, offering 8/11/13/24/30/70/97 channels for ultimate flexibility.

The SATURN700RGB is not just a luminary; it’s an experience. Discover the universe of possibilities with a TFT Display guiding your control, while a low-noise fan ensures cool serenity during your performance. Weighing in at 12.2kg and accompanied by power cable and x2 integrated clamps, this cosmic wonder is ready to take your events to new dimensions.



Specifications

  • Light source: 392pcs 1.5W CW+784 0.8W RGB
  • Output: ≥72600LM (Peak value)
  • Illuminance: 1600Lux@5m (117º)
  • Color temperature: 2700K-8000K
  • Power connection: IP Power IN/OUT
  • Data connections: IP DMX IN/OUT+IP RJ45+IP USB
  • Consumption: Power 700w, Strobe 1200W
  • Power factor: ≥0,95
  • LED Lifespan: 50K hrs
  • Beam angle: 117º
  • CRI: Ra≥90
  • Photocromic: R:623±3NM, G:525±3NM, B:455±3NM, W:6000±100K
  • Tilt movement: 185º
  • Strobe: Unique pulse mode
  • Dimmer: 4 dimming curves, 0~100% dimming
  • Pixel-mappable zones: 28 segment strobe white + 14-segment strobe color RGB
  • Control mode: DMX512/RDM/Art-Net
  • DMXchannel: 8/11/13/24/30/70/97CH
  • Display: TFT Display
  • Cooling: Low noise fan
  • Housing: Aluminium-magnesium allow, hot paint
  • IP Rating: IP65
  • Dimensions: 494 x 316 x 160 mm
  • Weight: 12,2Kg
  • Accesories: Power cable, x2 integrated Clamps



Downloads

SATURN700RGB

TitleDescriptionSizeDate modifiedDownload
SATURN700RGB-MANUALUSER MANUAL1.19 MB10-06-2024 DownloadPreview
SATURN700RGB-dwDIMENSIONAL DRAWING125.27 KB10-06-2024 DownloadPreview
SATURN700RGB-librariesLIBRARY FILE32.30 KB10-06-2024 Download
