Description
The LASERARRAY18RGB is a professional-grade RGB laser bar equipped with six high-brightness animation heads, specifically engineered for demanding stage and outdoor environments. Offering a total output of 18W RGB (per head: R700 mW + G800 mW + B1.5 W), this fixture delivers sharp beams, smooth color mixing, and stable graphics suitable for high-end productions.
With a robust yet lightweight chassis, it meets IP66 waterproof and dustproof standards, making it reliable for outdoor use under any weather conditions. The integrated 40kpps scanning system ensures precise visuals with wide-angle coverage. Multiple control options—including automatic, DMX512, FB4, and master-slave—allow seamless integration into complex lighting setups.
Ideal for concerts, world tours, commercial performances, and multimedia laser shows, the LASERARRAY18RGB combines durability, power, and precision in a single versatile unit.
Specifications
- Laser Output: 18W RGB total
- Laser Diodes (per head): R700 mW + G800 mW + B1.5 W × 6 heads
- Voltage Range: AC 100–240V, 50/60Hz
- Power Consumption: < 700W
- Modulation Type: Analog
- Scanning System: 40kpps high-speed scanner
- Scan Angle: Max ±30°
- Input Signal: ±5V
- Linearity Distortion: < 2%
- Beam Size & Divergence: 9 × 6.5 mm; < 1.0 mrad
- Control Modes: Automatic, DMX512 (16CH), FB4, Master-Slave
- Control System: FB4 – QuickShow
- Interfaces: Waterproof DMX512 in/out, waterproof LAN
- IP Rating: IP66 (suitable for outdoor use)
- Built-in Effects: 160 patterns (8 groups × 20 cues)
- Advanced Control Features: RDM bidirectional data, temperature control, DMX512 upgrade
- Applications: Concerts, festivals, outdoor stages, laser shows, commercial events
- Flight Case Dimensions: 75 × 60 × 44 cm
- Net Weight: 34 kg
- Gross Weight: 57 kg (flight case)
