Description
The Linear series light is a powerful LED wall washer, suitable for operation in all-weather conditions. It is small in size, light in weight, able to achieve seamless stitching. With flexible section control function, it is possible to realize colorful pixel effect for the hotels, shopping malls, buildings, square landscapes, municipals, bridges, and other outdoor landscape lighting projects to provide new lighting solutions.
TECHNICAL DATA/SPECIFICATIONS
| Model Number | ARWALL16L | ARWALL8M | ARWALL4S |
| LED Qty | 16pcs(1M) | 8pcs(0.5M) | 4pcs(0.3M) |
| Beam Angle | 20°/30°/40°/20*40°/60°Optional | ||
| Spot Angle | 40°/50°/75°/45*75°/100°Optional | ||
| Lumen | 1395lm | 865lm | 450lm |
| CRI | / | ||
| Color Temp. | RGB | ||
| Product Measurement | 1000*52*80MM(1M) | 510*52*80MM(0.5M) | 300*52*80MM(0.3M) |
| Weight | 2.5kg(1M) | 1.6kg(0.5M) | 1.2kg(0.3M) |
| Input Voltage | DC24V | ||
| Watts | 48W(1M) | 24W(0.5M) | 12W(0.3M) |
| Power Factor | >0.12 | ||
| Housing Material | Tensile Aluminum + die-cast aluminium | ||
| Color | Matt black / Grey | ||
| Cooling | Natural convection cooling | ||
| Control Protocol | DMX513 | ||
| Segmented Control | 4Section(1M)/ | 2 Section(0.5M)/ | 1Section(0.3M) |
| Channel | / | ||
| Power /Installation | Independent | ||
| Conection | black rubber cable 5 Pin In & Out | ||
| Power Linking | 3cs(1m) | 6pcs(0.5m) | 12pcs(0.3m) |
| DMX Linking | 32pcs(1M) | 64pcs(0.5M) | 128pcs(0.3M) |
| Certification | CE,RoHS | ||
| IP Grade | IP68 | ||
