Description
LEON.S600 SPOT is a professional high power 600W LED moving spot, incredible wide zoom 7-50°(1:7 ), high quality CMY color mixing and linear CTO, accurate gobo projection with fast and quiet pan/tilt movement. Adding the frost, can achieve a professional and large scale wash effect; It is an ideal product for TV, theatre, event, concert ,multi-functional hall.
Optical system.
- Light source: 600W module.
- Angle: 7°-50°.
- CRI: Ra> 70, (Ra>90 optional).
Electrical Specs.
- Voltage: 100-240VAC, 50/60Hz.
- power: 880W.
- Drive Current: 3A.
- Power Connection: Power in.
- Signal socket: 3pin I 5pin in and out, RJ45 in and out.
Control System.
- Pan/Tilt rotation: 540°/270°(8-16bit).
- Dimmer: 0-100%16Bit.
- Cooling: Forced Convection.
- Control: DMX512, ROM, ARTNET, W-DMX (optional).
- Display: On board Control, Custom Mode, 0-25Hz Strobe.
- Con Personality: STANDARD/26CHS, BASIC/23CHS.
- Special: Pan/Tilt movement blackout, User-selectable
pan/tilt ranges.
Work Environment.
- Ambient Temp: 0-45 t.
- IP Rated: IP20.
Effect synthetic system.
- Rotating Gobo: 7 Gobos+ White, Gobo-flow effect, Gobo shake,
Bi-directional rotation.
- Static Gobo: 1 OGobos+White, Gobo-flow effect, Gobo shake.
- Colors: One color wheel (7dichroic-filters+White, Rainbow-flow
effect).
- CMYK: CMYwheel, Linear CTO function.
- Prism: One piece of 5 F prisms with bi-directional rotation, Speed
Adjustable.
- Iris: 5-100% linearly adjustable with macro.
- Animation Wheel: Bi-directional rotation,Speed adjustfable.
- Focus: Motorized linear focus.
- Frost: 1 Frost filter.
Appearance.
- Size: 483x293x720mm.
- Weight: 32.5kg.
- Casing: Flame-retardant plastic (VO).
- Color: Black.
Certification.
- CE, MET
