AVALON400ZOOM

💧 IP65 Rated

AVALON400ZOOM is a powerful LED projector ideal for projecting images and logos on buildings and large surfaces. Equipped with precise zoom of 10º to 30º or 20º to 60º totally versatile thanks to its powerful Zoom for both long and short distance applications. With IP65 waterproof rating, the product is designed for all types of facilities, cultural tourism markets, live action performances, theme parks, hotels and other professional outdoor locations, live performances. 3-sided prism.

Features

  • Outdoor resistance thanks to its IP65.
  • Great durability and very low maintenance.
  • Control via DMX, RDM.
  • Electronic focus.
  • Gobo wheel and color wheel. Zoom.
  • Equipped with a superior optical system. Zoom range: 20°- 60°.
  • The color wheel with bright colors, the fixed gobo wheel, the rotating gobo wheel, the prism and the atomizing effect can be easily transformed. – The transformation of very soft dimming gray
  • The Gobos can be changed in a flexible way, with precise rotation and positioning, and a clear image of the logo.
  • Professional for the cultural tourism market, theme park, theme city, live show, bridge docks, etc.
SKU: AVALON400ZOOM2060 Categories: ,

Description

AVALON400ZOOM is a powerful LED projector ideal for projecting images and logos on buildings and large surfaces. Equipped with precise zoom of 10º to 30º or 20º to 60º totally versatile thanks to its powerful Zoom for both long and short distance applications. With IP65 waterproof rating, the product is designed for all types of facilities, cultural tourism markets, live action performances, theme parks, hotels and other professional outdoor locations, live performances. 3-sided prism.

Specifications

  • LED: Imported 400W cool white module
  • CCT: 7500K
  • Lumen: 10500lm
  • Beam angle: 10º to 30º lens or 20°- 60° lens
  • Input voltage: AC100-240V,50-60Hz
  • Power: 400W
  • Drive current: 13.5A
  • Dimming: 16Bit
  • Cooling: Natural heat dissipation +Fan
  • Control protocol: DMX512, RDM
  • DMX channel: 9CH,10CH
  • Function: Patterns and colors create a rainbow flow effect
  • Rotating wheel: 1 (6+1 rotating gobo, gobo shake, gobo bi-directional rotation, gobo can be customized)
  • Fixed wheel: 1(6+1 fixed gobo, gobo shake, gobo bi-directional rotation)
  • Color: Red, Green, Blue, Yellow, light blue, Magenta, Orange
  • Gobo size: Ø28.9 * Ø22
  • Prism: 3 prism
  • Focus: Electronic focus
  • Frost: 1 frost filter
  • Dimensions: 560x318x200mm
  • Weight: 13.5KG
  • Housing material: Die-casting Magnesium alloy
  • Housing color: Grey/Black
  • Power cable: Power in/out (3-pin rubber cable )
  • DMX cable: DMX in/out (3-pin rubber cable )
  • Electrical safety class: I
  • EMC: EMC,EMI
  • Permitted Ambient Temperature: -20 ~ +45ºC
  • IP Grade: IP65
